SF35Y | ||||
STANDARD DIMENSIONS | ||||
General | Model | SF35Y | unit | |
Load capacity | 3500 | Kg | ||
load center | 500 | mm | ||
Power type | Gasonline/LPG | |||
Dimensions | Lift size | 3000 | mm | |
Fork size | 1070x122x45 | mm | ||
Mast tilt angle | /6/12 | ° | ||
Front overhang | 495 | mm | ||
Overall dimensions | Length to face of fork | 3829 | mm | |
Overall width | 1226 | mm | ||
Overall height fork lowered | 2070 | mm | ||
Overhead guard height | 2070 | mm | ||
Turning radius | 2450 | mm | ||
Performance | travel speed(full load/no load) | 20/21 | Km/h | |
Lift speed with load | 520 | mm/sec | ||
Max.gradeability | 20 | % | ||
Self weight | 4560 | Kg | ||
Wheel&tires | Tires | Front | 28.9×9-15-15PR | |
Rear | 6.50-10-10PR | |||
tread | Front | 1000 | mm | |
Rear | 980 | mm | ||
Wheelbase | 1700 | mm | ||
Min.ground clearance(mast) | 110 | mm | ||
Drive units&control | Engine | Model | NISSAN K25 | |
Rated output | 37.4/2300 | Kw/rpm | ||
Rated torque | 176.5/1600 | N·m/rpm | ||
No.of cylinder | 4 | |||
Bore×stroke | 89×100 | mm | ||
Displacement | 2.488 | L |
