Main Specification | ||||
Engine | Model & type | Cummins NTA855-C360S10; In-line, water-cooled; 4-cycle, | ||
Rated revolution | 2000 rpm | |||
Horsepower | Gross power: 257/345/2000 kW/HP/rpm // | |||
Number of cylinders | 6—139.7 x 152.4 (mm x stroke) | |||
Piston displacement | 14010 ml | |||
Min. fuel consumption | 245 g/kW·h | |||
Maximum torque | 1440 N·m@1400rpm | |||
Power transmission system | Torque converter | 3-element, 1 stage, 1 phase | ||
Transmission | Planetary gear, multi-disc clutch, power shift, forced lubrication | |||
Main drive | Spiral bevel gear, splash lubrication, single-stage speed reduction | |||
Steering clutch | Wet, multi-disc, spring loaded, hydraulically separated, hydraulic control | |||
Steering brake | Wet, floating band, foot brake with hydraulic booster | |||
Final drive | 2-stage speed reduction of spur gear, splash lubrication | |||
Travel speed | Gear | 1st | 2nd | 3rd |
Forward | 0~3.6 km/h | 0~6.6 km/h | 0~11.5 km/h | |
Reverse | 0~4.4 km/h | 0~7.8 km/h | 0~13.5 km/h | |
Undercarriage | Type | Swing type of sprayed beam, suspended structure of equalizer bar | ||
Carrier rollers | 2 each side | |||
Track rollers | 7 each side (single flange 5, double flange 2) | |||
Track type | 41 each side | |||
Width of track shoes | 560 mm | |||
Pitch | 228.6 mm | |||
Hydraulic | Maximum pressure | 14 MPa | ||
Pump type | Gear pump | |||
Discharge (at revolution of 2000 rpm) | 355 (1795 rpm) L/min | |||
Bore of working cylinder × no. (double-acting type) | 140 mm × 2 | |||
Blade | Blade Type | Straight-tilt | Angle | Semi-U blade |
Dozing capacity | 10 m 3 | 6 m 3 | 11.9 m 3 | |
Efficiency | 580 m 3 /h | 350 m 3 /h | 690 m 3 /h | |
Blade width | 4130 mm | 5000 mm | 4130 mm | |
Blade height | 1590 mm | 1140 mm | 1710 mm | |
Maximum drop below ground | 560 mm | 630 mm | 560 mm | |
Maximum tilt adjustment | 1000 mm | 500 mm | 1000 mm | |
Weight of blade | 4520 kg | 4932 kg | 4924 kg | |
Riipper | Maximum digging | 842 mm | ||
Maximum lift above ground | 883 mm | |||
Weight of 3-shank ripper | 3802 kg | |||
Maximum digging | 1250 mm | |||
Maximum lift above ground | 965 mm | |||
Weight of single ripper | 3252 kg |
