Cab

Model

HW76

Engine

Model

WD615.47

Rated Power kW/rpm

273/2200

Max torque Nm/rpm

1460/1300-1600

Displacement L

9.726

Clutch

Φ430 diaphragm spring clutch, Hydraulic control air assisted.

transmission

HW19710

Front Axle

HF7 drum-type, rated load of 7t

Drive Axle

HW1667 single reduction, speed ratio:3.73,optional:4.22

Suspension

Front and rear leaf spring suspension, with shock absorber, transverse stabilizer

Steering system

ZF8098 steering gear, ZF steering oil pumb, system pressure 18MPa

Braking system

Service brake: dual-circuit air pressure brake;Parking system: spring storage energy without air;Auxiliary brake: engine exhaust braking;Optional: engine EVB, ABS and auto clearance adjusting arm.

Tyre

12.00-20; Optional:11.00-20

Tank volume L

400

Kerb weight(vehicle/chassis) kg

7180

Gross mass kg

18000

Authorized maximum towed mass kg

38600

Permissible fifth wheel load kg

10690

External dimensions(length x width x height) mm

6110×2496×2958

Wheelbase mm

3500

Fifth wheel joint ground clearance(unload) mm

1330/1297
