XCMG SD8N

specifications

Dozer

Tilt

Operating weight(including ripper)

kg

37300

Ground pressure

kpa

94

Track gauge

mm

2083

Gradient

°

30/25

Min. ground clearance

mm

556

Dozer capacity

m3

11.24

Blade width

mm

3940

Max. digging depth

mm

582

Overall dimensions(including ripper)

mm

7930x3940x3549

Engine

Type

Cummin NT855-C360S10

Rated revelation

rpm

2100

Engine power

kw

257

Torque storage coefficient

%

20

Undercarriage system

Type

The track is triangle shape.The sprocket is elevated elastic suspended.

Number of track rollers(each side)

8

Pitch

mm

216

Width of shoe

mm

560

Gear

Forward I/II/III

km/h

3.5/6.2/10.8

Backward I/II/III

km/h

4.7/8.1/13.9

Implement hydraulic system

Max. system pressure

Mpa

20

Pump type

Gears oil pump

System output

L/min

220

Driving system

Torque converter

Torque converter is power separating hydraulic-mechanic type

Transmission

Planetary, power shift transmission with three speeds forward and three speeds reverse,speed and direction can be quickly shifted.

Steering clutch

The steering clutch is hydraulic pressed, non-constant engaged clutch

Final drive

The final drive is two-stage planetary reduction gear mechanism, splash lubrication
